Efficient
1. Pure Sine wave with a voltage regulation of 97 % and at a frequency of 50 Hz
. 2. Peak generator efficiency of 95%
. 3.Self consumption of the inverter is as low as 3 W.
Robust
1. Robust in design and functionality
.2. Capable of taking high surge currents for starting and operation of inductive loads like motors, Air Conditioners , Heaters, Fridge etc
Simple
1. Built-in Solar charge controller allows you to connect solar modules directly to the generator.
2. Plug and play system ensures that system is easy to install.
3. System monitoring is provided by easy to interpret indications which allows for easy management and maintenance of the system.
Intelligent Battery Management
1. Four stage charging ensures high charging efficiency and longer battery life.
2. Switch mode settings for sealed and tubular batteries ensures optimal charging based on the type of battery.
3. Inbuilt Equalisation Mode ensures proper maintenance of batteries by destroying sulphate deposits on the battery lead plate.
4. ‘Low Voltage Disconnect’ avoids deep discharging of batteries which reduces their cycle times.
Flexible
1. The system can operate as a battery charger, a solar power generator and as an Uninterrupted Power Supply.
2. Grid Charging is possible through both automatic and manual modes to ensure maximum flexibility.
3. Transfer time is as low as 12 ms between Inverter and Grid mode to ensure power is uninterrupted.
Safety
1. Galvanic isolation between the DC input side and AC load side.
2. Built-in DC and AC heavy duty input breakers allow a safe and quick disconnection from the DC or AC circuits.
3. Short circuit protection, battery protection, overload protection and over-temperature protection ensures safe running of the system at all times avoiding risk to life and property
Continuous Power | : | 4000 W |
---|---|---|
Surge Rating @ 25'C | : | 12000W (5Sec), 8000W(15Sec) |
Idle Consumption | : | < 5 W |
Solar P.V Connected | : | 4000 W |
Solar Charge Controller Rating | : | 100 A dc |
Output Waveform | : | True Sine Wave |
Peak Efficiency | : | 95% |
Transfer Time | : | < 15 ms |
AC Connections | : | AC Grid or Generator |
AC Input / Pass through current | : | 1-50A dc |
AC Input Voltage Range | : | 180 - 250 VAC |
AC Input Frequency Range | : | 45 - 65Hz |
AC output Voltage Range | : | 220V - 240 VAC |
Frequency | : | 50Hz +/- 0.1Hz |
Total Harmonic Distortion | : | < 3% |
DC operating range | : | 43.2 - 64V |
Charging Type | : | PWM 4-Stage |
Max. Charging Current | : | 120 A Dc |
Max. PV Open Circuit voltage(UOC) | : | 92V dc |
Operation mode for Auxiliary Contact | : | Auto / Manual |
Power factor corrected charging | : | 0.98 |
Nominal DC input voltage | : | 48 VDC |
AC/DC Short-circuit | : | automatic disconnection |
AC/DC Overload | : | automatic shutdown |
Over temperature | : | automatic shutdown with automatic restart (after cooling) |
L.V.D | : | AC power cut off |
Batt. Reverse polarity | : | DC fuse protected |
Battery Input Circuit breaker | : | 200A dc |
DC battery fuse | : | 200A (10x 20A ) |
AC Input Circuit breaker | : | 50A dc |
DC solar input fuse | : | 3x 40A dc |
Dimensions (H*B*L) | : | 620*475*570 |
Weight | : | 85 kg |
